VM MRDR Aluminum Rear Wheels 12 X 12 (4 + 8 Offset)

Blacked Out Aluminum 12×12 Wheels (4+8 Offset)

Short Chrome Valve stems included

Sold in pairs.

These VM (4+8) wheels weigh about 8 pounds each.

This CNC spun aluminum wheel begins with a 4mm (0.156″) thickness. The inside is a large diameter smooth i.d. and the outside section is a deep lip with a large diameter opening with a chamfered outer edge to the bead. They are combined with a center plate and pressure tested for leaks at the weld.

This (4+8) offset wheel WILL accomodate stock cub-cadet external axle brakes.

The bolt pattern is (5) 0.505″ diameter bolt holes on a 4.5″ diameter bolt circle. There is a 2.75″ diameter hole through the center of the wheel inside the bolt pattern.
This is the stock cub-cadet bolt pattern as well as many Ford vehicles.

Heavy-duty bead locks.

If loosing clearance creates a problem, you would need run the appropriate spacers on the axle to widen the wheelbase back to acceptable clearances.
